Material:





Specifications:



Applications:






Shapes in Inventory: (click to view product)
SAE 841 Sintered Bronze / Powdered Metal

Powdered metal offer both strength and flexibility.  Additionally, they offer a cost effective production process that includes oil impregnation or permanent lubrication.

ASTM -  B438, Grade 1, Type II
Military - MIL-B-5687D, Type I, Grade I
MPIF - CT-1000-K26

Heavy industry uses Sintered Bronze as machinery components, as self-lubricating pump parts, and as turbine blades. The military depends on them for reliability in weapons and aircraft; and the technique is used to fabricate exotic materials for space vehicles.

Products > Sintered Bronze Products
Chemical Composition  (nominal composition)
     Cu               Fe       Pb           C                Sn       Mg  Acid Insolubles    Other
Nominal    87.5-90.5   1.0 max     -     1.75 max    9.5-10.5     -               -                      0.5
Mechanical & Physical Properties

Density (gm per cu. cm)
Porosity (% Oil by vol.)
"K" Strength Constant
Tensile Strength (PSI)
Elongation (% in one inch)
Yield Strength in Comp. (psi)
6.4-6.8
19 min.
26,500
14,000
1
11,000
Properties:
